ER20 スピンドルパワーヘッド 5000-6000RPM 防水 60mm 電動スピンドルユニットボーリング・フライス・ドリル加工用

$111.11 USD

~~$0.00 USD~~ $111.11 USD

セール売り切れ

税込。配送料はチェックアウト時に計算されます。

色 ER20(60)-1 ER20(60)-2 ER20(60)-3 ER20(60)-4 ER20(60)-5 ER20(60)-6

ER20 Power Head Boring Milling Spindle Head Unit 5000~6000rpm Waterproof 60mm

Shipping list

ER20(60) 3000rpm Drilling Power Head

Specifications

Model	ER20(60)-1	ER20(60)-2	ER20(60)-3	ER20(60)-4	ER20(60)-5	ER20(60)-6
Overall size	241.5x62x60mm	241.5x62x60mm	241.5x62x60mm	241.5x62x60mm	241.5x62x60mm	241.5x62x60mm
Axle head size	14x38mm	14x38mm	14x38mm	14x38mm	14x38mm	14x38mm
Central height	31mm	31mm	31mm	31mm	31mm	31mm
Clamping range	2-13mm	2-13mm	2-13mm	2-13mm	2-13mm	2-13mm
Run-out	0.01mm	0.01mm	0.01mm	0.01mm	0.01mm	0.01mm
Speed	3000rpm	3000rpm	5000~8000rpm	5000~8000rpm	5000~6000rpm	5000~6000rpm
Rising Temperature	within 25 Degree Celsius	within 25 Degree Celsius	within 25 Degree Celsius	within 25 Degree Celsius	within 25 Degree Celsius	within 25 Degree Celsius
Spindle Material	20CrmnTi, carburizing heat treatment	20CrmnTi, carburizing heat treatment	20CrmnTi, carburizing heat treatment	20CrmnTi, carburizing heat treatment	20CrmnTi, carburizing heat treatment	20CrmnTi, c arburizing heat treatment
Bearing	Deep groove ball bearing	Deep groove ball bearing	Imported Deep groove ball bearing	Imported Deep groove ball bearing	Angular contact matching bearing	Angular contact matching bearing
Bearing	70032,60031, 6002*2	70032,60031, 6002*2	70032,60031, 6002*2	70032,60031, 6002*2	70032,60031, 6002*2	70032,60031, 6002*2
application	Drilling Cutting Machine	Drilling Cutting Machine	Drilling Cutting Machine	Drilling Cutting Machine	Boring Milling Cutting Machine	Boring Milling Cutting Machine
waterproof	NO	YES	NO	YES	NO	YES

Advantage

(1) Higher precision, better stability and smoother operation.

(2) Adopting Japanese technology, double waterproof design structure, isolating cutting fluid and dust in production and processing, ensuring the good condition of the spindle head in actual work.( Waterproof function is only available on some models)

(3) The main shaft housing is cast in high-tough cast iron. After manual and natural double aging treatment, it is wear-resistant and not easily deformed.

Benefits for you

(1) Using better manufacturing technology, bring you a higher quality and more perfect experience.

(2) Excellent service, a variety of models to meet your needs.

Application area

This series of power heads is mainly suitable for drilling, boring and other work occasions.

ER20 Spindle Power Head 5000-6000RPM Waterproof 60mm Electric Spindle Unit for Boring Milling Drilling detail image 1
