M9710 Programmable DC Electronic Load | 150W 0-150V 0-30A Power Supply Tester 110V/220V
M9710 Programmable DC Electronic Load | 150W 0-150V 0-30A Power Supply Tester 110V/220V
Verfügbarkeit für Abholungen konnte nicht geladen werden
M9710 Programming DC electronic load 30A150V150W
Features:
- Six high speed operation modes: CC, CR, CV, CW, CC+CV, CR+CW
- Over current, over voltage, over power, over heat, polarity reversed protection
- High-luminance VFD screen with two lines& four channels display
- Intelligent fan system fan will be automatically initiated according to the temperature
- Soft start time setting, carrying the power supplier according to the voltage value set
- Battery testing and short-circuit function
- Available of dynamic testing and rising edge and falling edge setting
- Supporting external trigger input and output
- External current waveform monitor terminal
- Supporting remote voltage compensation and multidata storage
- Power-on-self-test, software calibration and standard rack mount
- Communication mode: RS232/RS485/USB.
Application:
Production line(cell phone charger, cell phone battery, electric vehicle battery, switching power supplier, linear power supplier), research institutes, automotive electronics, aeronautics and astronautics, ships, solar cells fuel cell, etc.
Specification:
Model |
M9710 |
||
Input Rating |
Power |
150W |
|
Current |
0-30A |
||
Voltage |
0-150V |
||
CC Mode |
Range |
0-3A |
0-30A |
Resolution |
0.1mA |
1mA |
|
Accuracy |
0.03%+0.05%FS |
0.03%+0.05%FS |
|
CV Mode |
Range |
0.1-19.999V |
0.1-150V |
Resolution |
1mV |
10mV |
|
Accuracy |
0.03%+0.05%FS |
0.03%+0.05%FS |
|
CR Mode |
Range |
0.03-10K Oh |
0.03-5K Oh |
Resolution |
16 bit |
16 bit |
|
Accuracy |
0.1%+0.1%FS |
0.1%+0.1%FS |
|
CW Mode |
Range |
0-150W |
0-150W |
Resolution |
1mW |
10mW |
|
Accuracy |
0.2%+0.2%FS |
0.2%+0.2%FS |
|
Voltage Measurement |
Voltage |
0-19.999V |
0-150V |
Resolution |
1mV |
10mV |
|
Accuracy |
0.015%+0.05%FS |
0.015%+0.05%FS |
|
Current Measurement |
Current |
0-3A |
0-30A |
Resolution |
0.01mA |
0.1mA |
|
Accuracy |
0.05%+0.1%FS |
0.05%+0.1%FS |
|
Power Measurement |
Power |
100W |
150W |
Resolution |
1mW |
10mW |
|
Accuracy |
0.2%+0.2%FS |
0.2%+0.2%FS |
|
Battery Test |
Battery Input: 0.5-120V; Max. Measurement: Capacity = 999AH; Resolution=0.1mA; Test Range=1S-32H |
||
Dynamic Test |
Transition List:0-5kHZ; ; T1&T2:60uS-999S; Accuracy:+15% offset+10%FS |
||
Current soft-startup Time |
2mS;5mS;10mS;20mS;50mS;100mS;200mS;500mS;1000mS Accuracy:+15% offset+10%FS |
||
Short Circuit |
Current(CC) |
=3.3A |
=33A |
Voltage(CV) |
0V |
||
Resistance(CR) |
=55mOh |
||
Temperature |
Operating |
0~40oC |
|
Stocking |
-10oC~70oC |
||
Dimension |
W*H*D(mm) |
214*108*365 |
|
Weight |
Kg |
3.5 |
|
