KT50 Optical Radius Angle Dresser | Perspective Grinding Wheel Dresser Visual Precision 0.01mm

KT50 Perspective Grinding Wheel Dresser Visual Optical Radius Angle Dresser 0.01

Description:

Perspective Dresser, suitable for surface grinding machine and universal tool grinder. Can be trimmed to a variety of angles and bump R, is accessible via the endoscope diamond tip dressing grinding wheel surface contact situation, the precise finishing of small arcs and angles.

Specifications:

Precision: 0.01MM
Center height: 65 MM
Dressing grinding wheel diameter: Ф200 MM
Dressing ARC min size: Ф0.5MM
Convex R trim range: 0-12 MM
Concave R trim range: 0-25.4 MM
Skateboard finishing stroke: 22.5 MM
Trim angle: 95 degree - 0 degree - 95 degree
Throught Hole diameter: Ф30 MM
Size: 230 x 75 x 97 MM
Weight: 3.8kg

Package included:

1 x KT50 Perspective Grinding Wheel Dresser
