ITECH IT8211 Digital Control Electronic Load (60V / 30A / 150W)

The IT8211 digital control electronic load is a high-precision and high-resolution testing instrument suitable for various DC power supply testing applications. It provides constant current (CC), constant voltage (CV), and constant resistance (CR) operation modes, with easy-to-use interface and reliable protection functions.

⚙️ Main Features

• Digital control electronic load

• Voltage range: 0–60V, Current range: 1mA–30A, Power: 150W

• Full range 10mV / 1mA resolution

• Working modes: CC / CV / CR

• Highlight LED display

• Input on/off control

• High reliability with OC / OV / OP protection

• Programmable LIST mode (25×4 sets)

• Storage for 4×40 preset values

• Compact size and easy operation

📟 Operation Modes

• CC Mode (Constant Current): The load absorbs the current value you set.

• CV Mode (Constant Voltage): The load consumes enough current to maintain the preset voltage value.

• CR Mode (Constant Resistance): The load consumes current in linear proportion to input voltage.

🔋 Input Ratings (0~40°C)

📊 Regulation and Measurement

• CV Mode: 0.1–60V ±(0.05%+0.1%FS)

• CC Mode: 0–30A ±(0.1%+0.15%FS)

• CR Mode: 0.1Ω–4KΩ ±(1%+0.8%FS)

• Voltage Measurement: ±(0.05%+0.1%FS)

• Current Measurement: ±(0.1%+0.15%FS)

• Power Measurement: ±(1%+0.5%FS)

💾 Functions

• Input on/off control

• OCP (Over Current Protection) setup

• REL (Real-time reveal) function

• BEEP sound on/off setting

• Address (ADD) setting: 0–31

• Group (GRP) storage: 40 groups

• Short-circuit test function

• LIST programmable function with 0.4–25s delay and 100 steps (A/B/C/D groups)

⚡ Short-Circuit Operation

The IT8211 can simulate a short circuit at its input by turning on full-scale current. The short circuit can be toggled on/off at the front panel. The actual short-circuit current depends on the working mode and current range when the short is turned on.

📐 Dimensions

88 × 175 × 282 mm
